Products Description
Overview
12 Fiber MPO(Male)-6LC Duplex OM3 Multi-mode Fiber Optic Harness Fan-out/Breakout Cable provides a flexible, high-density solution for integrating MPO-based high-speed systems with LC duplex infrastructure. Featuring a male 12-fiber MPO connector on one end and six LC duplex connectors on the other, this cable bridges 40G/100G/400G MPO trunk lines (e.g., QSFP+/QSFP28 transceivers) with 10G SFP+ devices, enabling seamless connectivity in data centers, enterprise networks, and storage environments. Built with OM3 50/125μm laser-optimized multi-mode fiber, it supports 10Gbps speeds up to 300 meters and 40G/100G transmission at 100 meters, ensuring reliable performance for bandwidth-intensive applications.
The ruggedized MPO(Male) connector ensures precise alignment and low insertion loss, while the LC duplex ends offer secure, standardized compatibility with switches and servers. Its breakout design simplifies cabling by eliminating intermediate adapters, reducing clutter, and streamlining high-density deployments. Compliant with TIA/EIA and IEC standards, this harness cable combines durability, scalability, and future-proof flexibility, making it ideal for cloud infrastructure, parallel optics, and evolving network architectures demanding efficient, space-saving connectivity.
Item Specifications:
| Connector A | MPO (Female) | Connector B | LC UPC (6) |
| Fiber Mode | 50/125μm OM3 | Cable Diameter | 3.0mm |
| Fiber Count | 12 | Wavelength | 850nm |
| Breakout Length | 0.5m | Fiber Type | Duplex |
| Cable Jacket | PVC | Insertion Loss | <=0.6dB |
| Jacket Color | Aqua | Return Loss | MTP>=20 dB, LC>=30dB |
| Operate Temperature | -40~75°C | Durability | >=500 times |
Features:
A single MPO connector on one end that breaks out into 4LC connectors
Designed to save front panel space and streamline fiber management
Support use in attaching directly to 40G transceivers
Compliant to IEC-61754-7 and TIA-604-5(FOCIS-5) standard
Applications:
Data Centers with High Density Requirement
Fiber Channel Storage
Parallel Processing Applications
Telecommunications and Backbone Installations
