Overview

100G BIDI QSFP28 enables bidirectional data transmission through a single fiber, which means data can be sent and received on the same fiber. It is used in 100G Ethernet applications in data centers, switches, routers, transmission equipment, servers, and supercomputer interconnects. It is a solution that features high density and cost-saving.

Features

● Supports 100GBASE-LR1/ER1 BIDI

● Lane signaling rate 106.25Gb/s with PAM4

● 4x25.78Gb/s with NRZ electrical interface (CAUI-4)

● Support KP4 FEC inside the module

● High speed I/O electrical interface

● I2C interface with integrated Digital Diagnostic monitoring

● QSFP28 MSA package with simplex LC connector

● Single +3.3V power supply

● Operating case temperature: 0 to +70 °C

● Compliant to 802.3cu, SFF-8636&SFF-8679 standard

● Compliant to 100G Lambda MSA 100G-LR1/ER1 Optical Specifications

● Complies with EU Directive 2015/863/E

Application

● Data Center

● 100 Gigabit Ethernet

● Switch to Switch interface

● Router/Server interface
